Technical Specifications
| Specification | Details |
|---|---|
| Product Name | Water Distillation Apparatus |
| Model No. | 1381e |
| Brand | LABIX |
| Boiler Material | Quartz Boiler |
| Condenser Material | Borosilicate Glass 3.3 |
| Heating System | Inbuilt Electric Heater |
| Safety Feature | Automatic Safety Cut-Off Device |
| Mounting | Complete with Stand & Clamps |
| Distillate Quality | Suitable for HPLC Applications |
| Output Capacity Option 1 | Approx. 2.0 Ltr/hr |
| Output Capacity Option 2 | Approx. 5.0 Ltr/hr |
| Construction | Corrosion & Chemical Resistant |
| Application | Production of High-Purity Distilled Water |
Key Features
- High-performance water distillation apparatus for laboratory-grade distilled water production.
- Quartz boiler ensures excellent purity and durability.
- Borosilicate Glass 3.3 condenser provides efficient condensation.
- Suitable for HPLC, analytical, and research applications.
- Integrated electric heating system for continuous operation.
- Automatic safety cut-off for enhanced user protection.
- Corrosion-resistant construction for long service life.
- Easy installation with complete stand and clamp assembly.
- Low maintenance and reliable operation.
- Produces high-quality distilled water free from most contaminants.
Working Principle
The water distillation apparatus works on the principle of evaporation and condensation. Raw water is introduced into the quartz boiler, where the inbuilt heater raises the temperature until the water boils. The generated steam leaves behind dissolved impurities, minerals, and contaminants. The steam then passes through the borosilicate glass condenser, where it is cooled and converted back into liquid form. The resulting distilled water is collected separately, ensuring a high level of purity suitable for laboratory applications.
Applications
- HPLC Laboratories
- Pharmaceutical Industries
- Chemical Laboratories
- Research & Development Centers
- Educational Institutions
- Hospitals & Healthcare Laboratories
- Quality Control Laboratories
- Analytical Testing Facilities
Wrapping Notes
The LABIX Water Distillation Apparatus Model is a reliable solution for producing high-purity distilled water required in modern laboratories. Equipped with a quartz boiler, borosilicate glass condenser, built-in heater, and safety cut-off system, this water distillation apparatus delivers consistent performance, operational safety, and excellent water quality for scientific, pharmaceutical, and analytical applications.
